Complete Diesel Engine for Cummins 4BTAA

For Cummins: General reference: turbocharged and aftercooled Certification: EURO II Weigh dry (with flywheel and alternator,but less starter and air compressor): 395kg Weigh wet: 411kg CGdistance from FFOB: 328mm CG distance above crank center line:155mm Maximum bending moment at RFOB: 1356Nm Thrust bearing loadlimit Maximum intermittent: 3781N Maximum continuous: 1,780N Performance data Idle speed: 750rpm Maximum no load governed speed: 3,100rpm Maximumoverspeed capability (15 seconds maximum): 4,200rpm Maximum altitude for continuous operation: 3,000m Clutch engagement torque at 800rpm:380Nm When using exhaust brakesExhaust pressure, at 2,720rpm, atturbocharger outlet, must not exceed: 414kPa Approximate engine retardation: 112kW Advertised power: 130kW at 2,700rpm Peak torque: 502Nmat 1,400-1,600rpm
